System data
• Frequency response (-5 dB standard) : 45 Hz – 18 kHz
• Frequency response (-5 dB CUT mode) : 70 Hz – 18 kHz
• Max. sound pressure (1m, free field) with D80 : 150 dB
• Cabinets per D80 (ArrayProcessing) : 2

Loudspeaker data
• Nominal impedance front LF : 4 ohms
• Nominal impedance side LF/MF/HF : 4 ohms
• Power handling capacity front LF (RMS/peak 10 ms) : 800/3200 W
• Power handling capacity side LF/MF/HF (RMS/peak 10 ms) : 800/3200 W
• Nominal dispersion angle (horizontal) : 80 °
• Splay angle settings : 0 … 7° (1° increment)
• Components : 2 x 14″ front LF driver, 2 x 10″ side LF driver, 1 x 10″ MF driver, 3 x 1.4″ exit compression driver with 3.4″ coil, Passive crossover network
• Connections : 1 x NLT4 F

Dimensions / weight
• Dimensions (H x W x D) : 391 x 1300 x 627 mm
• Weight : 80 kg
